The Masters M28 Seven Channel Power Amplifier represents the epitome of modern amplification technology, incorporating Purifi’s revolutionary Eigentakt™ amplifier technology. With a conservative rating of 200W per channel (8 ohms) and an impressive dynamic power of over 320W (8 ohms; all channels driven), the M28 delivers a truly remarkable surround sound experience. Whether tackling the explosive dynamics of the latest action film or delicately reproducing detailed passages in a classical piece, this amplifier captivates with its lifelike performance. Supporting both balanced and single-ended inputs, it features high-quality binding posts for speaker connections. Despite its compact dimensions, this energy-efficient design conceals a substantial power reservoir, making the M28 an ideal choice for the most demanding music and movie enthusiasts.
The Masters M28 Seven Channel Power Amplifier represents the epitome of modern amplification technology, incorporating Purifi’s revolutionary Eigentakt™ amplifier technology. With a conservative rating of 200W per channel (8 ohms) and an impressive dynamic power of over 320W (8 ohms; all channels driven), the M28 delivers a truly remarkable surround sound experience. Whether tackling the explosive dynamics of the latest action film or delicately reproducing detailed passages in a classical piece, this amplifier captivates with its lifelike performance. Supporting both balanced and single-ended inputs, it features high-quality binding posts for speaker connections. Despite its compact dimensions, this energy-efficient design conceals a substantial power reservoir, making the M28 an ideal choice for the most demanding music and movie enthusiasts.
| OVERALL SPECIFICATIONS | |
|---|---|
| OVERALL SPECIFICATIONS FTC power, two channels | ≥ 220 W (ref. rated THD, 8 Ohms , 20 Hz – 20 kHz, two channels driven) |
| OVERALL SPECIFICATIONS | ≥ 400 W (ref. rated THD, 4 Ohms , 20 Hz – 20 kHz, two channels driven) |
| OVERALL SPECIFICATIONS Rated power, all channels | ≥ 200 W (ref. rated THD, 8 Ohms , 20 Hz – 20 kHz, all channels driven) |
| OVERALL SPECIFICATIONS | ≥ 340 W (ref. rated THD, 4 Ohms , 20 Hz – 20 kHz, all channels driven) |
| OVERALL SPECIFICATIONS Rated THD (250 mW to rated power, CCIF IMD, DIM 100) | ≤0.003 % (ref. 20 Hz – 20 kHz) |
| OVERALL SPECIFICATIONS IHF dynamic power | 280 W 8 Ohms, (all channels driven) |
| OVERALL SPECIFICATIONS | 560 W 4 Ohms, (one channel driven) |
| OVERALL SPECIFICATIONS Damping factor | 1.3 V (ref. rated power) |
| OVERALL SPECIFICATIONS Input impedance | 47 kΩ (Balanced) |
| OVERALL SPECIFICATIONS Input Impedance (r and c) | 23 kΩ (Single-ended) |
| OVERALL SPECIFICATIONS | >118dB (ref. rated power) |
| OVERALL SPECIFICATIONS Damping Factor | >750dB (ref. 8 Ohms, 50Hz and 1kHz) |
| OVERALL SPECIFICATIONS Frequency Response | ±0.1dB (ref. 20Hz-20kHz) |
| OVERALL SPECIFICATIONS | -2.5dB at 3Hz and 100kHz |
| OVERALL SPECIFICATIONS Input Impedance | 47 kilohm (Balanced) |
| OVERALL SPECIFICATIONS Signal/noise ratio | > 102dB (A-weighted ref. 1W, Balanced) |
| OVERALL SPECIFICATIONS | > 97 dB (A-weighted ref. 1W, Single-ended) |
| OVERALL SPECIFICATIONS | > 124 dB (A-weighted ref. rated power, Balanced) |
| OVERALL SPECIFICATIONS | > 120 dB (A-weighted ref. rated power, Single-ended) |
| OVERALL SPECIFICATIONS Frequency response | ± 0.1 dB (ref. 20 Hz – 20 kHz) |
| OVERALL SPECIFICATIONS | – 3 dB at 3 Hz to 60 kHz |
| OVERALL SPECIFICATIONS Time to go to Standby mode at no input signal | ≤ 30 minutes |
| OVERALL SPECIFICATIONS Standby power | ≤ 0.5W |
| DIMENSIONS AND WEIGHT | |
|---|---|
| DIMENSIONS AND WEIGHT Gross dimensions WxHxD | 435 x 156 x 380 mm (17 3/16 x 6 3/16 x 15”) |
| DIMENSIONS AND WEIGHT Shipping Weight | 21.2 kg (46.7 lbs) |
Eigentakt™ Precision
The Masters M28 incorporates Purifi’s groundbreaking Eigentakt™ amplifier technology, licensed to NAD. This innovation ensures unparalleled precision, accounting for the effects of the output filter in the feedback loop and refining self-oscillating Class D tech. It achieves near-theoretical limit performance, delivering clarity and power, whether at low or peak volumes.
Impervious Load Handling
Unlike many class D amplifiers, the M28 remains impervious to loudspeaker load variations. It maintains a wide and consistent bandwidth response across different impedances, offering a continuous 200W into 8 ohms for all channels simultaneously. With 700W dynamic power into 4 ohms, this amplifier effortlessly handles diverse speaker setups, ensuring a reliable and powerful performance.
Analogue-Like Clipping Recovery
The Eigentakt™ technology ensures stable behavior even in clipping scenarios, resembling the benign clipping recovery of traditional class A/B amplifiers. This feature provides a safety net during intense audio demands, preventing instability and ensuring a smooth, controlled response, contributing to a secure and enjoyable listening experience.
Fully Balanced Audio Prowess
The M28 boasts a fully balanced audio interface, mirroring those used in professional studios. With locking connectors and specialized interface electronics, it guarantees the highest signal integrity and a minimal noise floor. This efficient design allows extended cable runs without compromising signal quality, delivering an immersive, noise-free audio experience in home theater setups.
Eigentakt™ Precision
The Masters M28 incorporates Purifi’s groundbreaking Eigentakt™ amplifier technology, licensed to NAD. This innovation ensures unparalleled precision, accounting for the effects of the output filter in the feedback loop and refining self-oscillating Class D tech. It achieves near-theoretical limit performance, delivering clarity and power, whether at low or peak volumes.
Impervious Load Handling
Unlike many class D amplifiers, the M28 remains impervious to loudspeaker load variations. It maintains a wide and consistent bandwidth response across different impedances, offering a continuous 200W into 8 ohms for all channels simultaneously. With 700W dynamic power into 4 ohms, this amplifier effortlessly handles diverse speaker setups, ensuring a reliable and powerful performance.
Analogue-Like Clipping Recovery
The Eigentakt™ technology ensures stable behavior even in clipping scenarios, resembling the benign clipping recovery of traditional class A/B amplifiers. This feature provides a safety net during intense audio demands, preventing instability and ensuring a smooth, controlled response, contributing to a secure and enjoyable listening experience.
Fully Balanced Audio Prowess
The M28 boasts a fully balanced audio interface, mirroring those used in professional studios. With locking connectors and specialized interface electronics, it guarantees the highest signal integrity and a minimal noise floor. This efficient design allows extended cable runs without compromising signal quality, delivering an immersive, noise-free audio experience in home theater setups.
