AMPLIFIERS
NAD D 3045
Hybrid Digital DAC Amplifier
AMPLIFIERS
NAD D 3045
Hybrid Digital DAC Amplifier
- overview
- specifications
- features
- gallery
- downloads
The NAD D 3045 embodies the ideal characteristics of a contemporary amplifier: it is compact, energy-efficient, powerful, silent, and equipped with cutting-edge features such as DSD and MQA playback. This amplifier, with NAD’s proficiency in both digital and analog engineering, showcases a perfect blend of versatility and affordability. It is an excellent choice for those seeking a high-resolution-capable, Bluetooth-enabled power amplifier with modern features.
The NAD D 3045 embodies the ideal characteristics of a contemporary amplifier: it is compact, energy-efficient, powerful, silent, and equipped with cutting-edge features such as DSD and MQA playback. This amplifier, with NAD’s proficiency in both digital and analog engineering, showcases a perfect blend of versatility and affordability. It is an excellent choice for those seeking a high-resolution-capable, Bluetooth-enabled power amplifier with modern features.
| PREAMPLIFIER SECTION LINE INPUT/PRE OUT | |
|---|---|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
THD (20Hz – 20kHz))
|
<0.003% at 2V out
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Signal-to-Noise Ratio
|
>100dB (IHF, A-weighted, ref. 500mV out, unity gain)
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Channel separation
|
>85dB (1kHz)
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
|
>80dB (10kHz)
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Input Impedance (R and C)
|
47kohms + 220pF
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Maximum input signal
|
>5.5Vrms (ref. 0.1% THD)
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Output impedance
|
400 Ohms
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Input sensitivity
|
82mV (ref. 500mV out, Volume maximum)
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Frequency response
|
±0.2dB (20Hz – 20kHz)
|
|
PREAMPLIFIER SECTION LINE INPUT/PRE OUT
Maximum voltage output -IHF load
|
>4V (ref. 0.1% THD)
|
| PHONO INPUT / PRE OUT | |
|---|---|
|
PHONO INPUT / PRE OUT
THD (20Hz – 20kHz)
|
<0.015% at 2V out
|
|
PHONO INPUT / PRE OUT
Signal-to-Noise Ratio
|
>82dB (200 Ohm source, A-weighted, ref. 500mV out)
|
|
PHONO INPUT / PRE OUT
|
>76dB (MM cartridge source, IHF; A-weighted, ref. 500mV out)
|
|
PHONO INPUT / PRE OUT
Input sensitivity
|
1.35mV (ref. 500mV out, Volume maximum)
|
|
PHONO INPUT / PRE OUT
Maximum input signal at 1kHz
|
>90mVrms (ref. 0.1% THD)
|
|
PHONO INPUT / PRE OUT
Frequency response
|
±0.3dB (20Hz – 20kHz)
|
| LINE INPUT, HEADPHONE OUT | |
|---|---|
|
LINE INPUT, HEADPHONE OUT
THD (20Hz – 20kHz)
|
<0.003% at 120mW
|
|
LINE INPUT, HEADPHONE OUT
Signal-to-Noise Ratio
|
>90dB (32 Ohm load; A-weighted, ref. 500mV out, unity gain)
|
|
LINE INPUT, HEADPHONE OUT
Frequency response
|
±0.3dB (20Hz – 20kHz)
|
|
LINE INPUT, HEADPHONE OUT
Output impedance 2 ohms
|
Maximum headphone output – 32 Ohm load <8V (ref. 0.1% THD)
|
| GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT | |
|---|---|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Continuous output power into 4 and 8 Ohms
|
60W (ref. 20Hz-20kHz at 0.03% THD, both channels driven)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
THD (20 Hz – 20 kHz)
|
<0.005% (at 1W, 4 and 8 ohms)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Signal-to-Noise Ratio
|
>98dB (A-weighted, 500mV input, ref. 2.828V out in 4
Ohms) |
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Clipping power
|
>80W (at 1kHz 4 Ohms 0.1% THD)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
IHF dynamic power
|
8 Ohms : 80W
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
|
4 Ohms : 150W
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
|
2 Ohms : 200W
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Peak output current
|
>18A (in 1 Ohm, 1ms)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Damping factor
|
>300 (ref. 8 Ohms, 20Hz to 6.5kHz)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Frequency response
|
±0.3dB (20Hz – 20kHz)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Channel separation
|
>75dB (1kHz)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
|
>70dB (10kHz)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Input sensitivity
|
260mV (for 30W in 4 Ohms)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Supports bit rate/sample rate
|
up to 24 bit/192kHz (digital source)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
|
up to 24 bit/384kHz (computer source)
|
|
GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Standby power
|
<0.5W
|
| DIMENSION AND WEIGHT | |
|---|---|
|
DIMENSION AND WEIGHT
Gross dimensions (W x H x D)*
|
70 x 235 x 265 mm
|
|
DIMENSION AND WEIGHT
|
2 13/16 x 9 5/16 x 10 7/16 inches**
|
|
DIMENSION AND WEIGHT
Net weight
|
3.6kg (7.9lb)
|
|
DIMENSION AND WEIGHT
Shipping weight
|
2.6kg (5.7lb)
|
High-Resolution Audio Excellence
The NAD D 3045 delivers a lifelike and natural listening experience with High-Resolution Audio capabilities. Master Quality Authenticated (MQA) ensures accurate reproduction of Studio Master recordings, providing music enthusiasts with the full spectrum of sound. High Res downloads and streaming offer an artist’s studio experience, unmatched in fidelity.
Versatile Connectivity Options
The D 3045 is equipped with diverse inputs and circuits to accommodate your entire music collection. An Asynchronous USB input facilitates High Res streaming from computers using precision clock technology, minimizing jitter. Bluetooth wireless streaming with aptX HD caters to everyday convenience, while the inclusion of a Moving Magnet Phono preamp ensures optimal performance for vinyl enthusiasts.
Cutting-Edge Features, Unmatched Value
Standout features include a super-accurate Moving Magnet Phono preamp, digital and analog inputs for CDs, and a High Res DAC for advanced audio processing. HDMI ARC input allows seamless integration with your TV, controllable using your TV’s remote. The inclusion of a Sub Out jack provides flexibility to enhance your system with a subwoofer.
Premium Performance at an Affordable Price
The NAD D 3045 combines advanced capabilities typically found in more expensive components. Its High Res USB DACs and headphone amplifiers surpass competitors in cost-effectiveness. With 60wpc, low distortion, and high current capability, this power amplifier provides rare performance at its price point. Enjoy 45 years of audio excellence in one compact, energy-efficient, and iconic NAD package.
High-Resolution Audio Excellence
The NAD D 3045 delivers a lifelike and natural listening experience with High-Resolution Audio capabilities. Master Quality Authenticated (MQA) ensures accurate reproduction of Studio Master recordings, providing music enthusiasts with the full spectrum of sound. High Res downloads and streaming offer an artist’s studio experience, unmatched in fidelity.
Versatile Connectivity Options
The D 3045 is equipped with diverse inputs and circuits to accommodate your entire music collection. An Asynchronous USB input facilitates High Res streaming from computers using precision clock technology, minimizing jitter. Bluetooth wireless streaming with aptX HD caters to everyday convenience, while the inclusion of a Moving Magnet Phono preamp ensures optimal performance for vinyl enthusiasts.
Cutting-Edge Features, Unmatched Value
Standout features include a super-accurate Moving Magnet Phono preamp, digital and analog inputs for CDs, and a High Res DAC for advanced audio processing. HDMI ARC input allows seamless integration with your TV, controllable using your TV’s remote. The inclusion of a Sub Out jack provides flexibility to enhance your system with a subwoofer.
Premium Performance at an Affordable Price
The NAD D 3045 combines advanced capabilities typically found in more expensive components. Its High Res USB DACs and headphone amplifiers surpass competitors in cost-effectiveness. With 60wpc, low distortion, and high current capability, this power amplifier provides rare performance at its price point. Enjoy 45 years of audio excellence in one compact, energy-efficient, and iconic NAD package.
MANUAL
DATA SHEET
SOFTWARE
To download a copy of the firmware for your NAD unit please contact support
MANUAL
DATA SHEET
SOFTWARE
To download a copy of the firmware for your NAD unit please contact support
The NAD D 3045 embodies the ideal characteristics of a contemporary amplifier: it is compact, energy-efficient, powerful, silent, and equipped with cutting-edge features such as DSD and MQA playback. This amplifier, with NAD’s proficiency in both digital and analog engineering, showcases a perfect blend of versatility and affordability. It is an excellent choice for those seeking a high-resolution-capable, Bluetooth-enabled power amplifier with modern features.
The NAD D 3045 embodies the ideal characteristics of a contemporary amplifier: it is compact, energy-efficient, powerful, silent, and equipped with cutting-edge features such as DSD and MQA playback. This amplifier, with NAD’s proficiency in both digital and analog engineering, showcases a perfect blend of versatility and affordability. It is an excellent choice for those seeking a high-resolution-capable, Bluetooth-enabled power amplifier with modern features.
| PREAMPLIFIER SECTION LINE INPUT/PRE OUT | |
|---|---|
| THD (20Hz – 20kHz) | <0.003% at 2V out |
| Signal-to-Noise Ratio | >100dB (IHF, A-weighted, ref. 500mV out, unity gain) |
| Channel separation | >85dB (1kHz) |
| >80dB (10kHz) | |
| Input impedance (R and C) | 47kohms + 220pF |
| Maximum input signal | >5.5Vrms (ref. 0.1% THD) |
| Output impedance | 400 Ohms |
| Input sensitivity | 82mV (ref. 500mV out, Volume maximum) |
| Frequency response | ±0.2dB (20Hz – 20kHz) |
| Maximum voltage output – IHF load | >4V (ref. 0.1% THD) |
| PHONO INPUT / PRE OUT | |
|---|---|
| THD (20Hz - 20kHz) | <0.015% at 2V out |
| Signal-to-Noise Ratio | >82dB (200 Ohm source, A-weighted, ref. 500mV out) |
| >76dB (MM cartridge source, IHF; A-weighted, ref. 500mV out) | |
| Input sensitivity | 1.35mV (ref. 500mV out, Volume maximum) |
| Maximum input signal at 1kHz | >90mVrms (ref. 0.1% THD) |
| Frequency response | ±0.3dB (20Hz – 20kHz) |
| LINE INPUT / HEADPHONE OUT | |
|---|---|
| THD (20Hz – 20kHz) | <0.003% at 120mW |
| Signal-to-Noise Ratio | >90dB (32 Ohm load; A-weighted, ref. 500mV out, unity gain) |
| Frequency response | ±0.3dB (20Hz – 20kHz) |
| Output impedance 2 Ohms | Maximum headphone output – 32 Ohm load <8V (ref. 0.1% THD) |
| GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT | |
|---|---|
| Continuous output power into 4 and 8 Ohms | 60W (ref. 20Hz-20kHz at 0.03% THD, both channels driven) |
| THD (20Hz – 20kHz) | <0.005% (at 1W, 4 and 8 ohms) |
| Signal-to-Noise Ratio | >98dB (A-weighted, 500mV input, ref. 2.828V out in 4 Ohms) |
| Clipping power | >80W (at 1kHz 4 Ohms 0.1% THD) |
| IHF dynamic power | 8 Ohms : 80W |
| 4 Ohms : 150W | |
| 2 Ohms : 200W | |
| Peak output current | >18A (in 1 Ohm, 1ms) |
| Damping factor | >300 (ref. 8 Ohms, 20Hz to 6.5kHz) |
| Frequency response | ±0.3dB (20Hz – 20kHz) |
| Channel separation | >75dB (1kHz) |
| >70dB (10kHz) | |
| Input sensitivity | 260mV (for 30W in 4 Ohms) |
| Supports bit rate/sample rate | up to 24 bit/192kHz (digital source) |
| up to 24 bit/384kHz (computer source) | |
| Standby power | <0.5W |
| DIMENSION AND WEIGHT | |
|---|---|
| Gross dimensions (W x H x D)* | 70 x 235 x 265 mm |
| 2 13/16 x 9 5/16 x 10 7/16 inches** | |
| Net weight | 3.6kg (7.9lb) |
| Shipping weight | 2.6kg (5.7lb) |
High-Resolution Audio Excellence
The NAD D 3045 delivers a lifelike and natural listening experience with High-Resolution Audio capabilities. Master Quality Authenticated (MQA) ensures accurate reproduction of Studio Master recordings, providing music enthusiasts with the full spectrum of sound. High Res downloads and streaming offer an artist’s studio experience, unmatched in fidelity.
Versatile Connectivity Options
The D 3045 is equipped with diverse inputs and circuits to accommodate your entire music collection. An Asynchronous USB input facilitates High Res streaming from computers using precision clock technology, minimizing jitter. Bluetooth wireless streaming with aptX HD caters to everyday convenience, while the inclusion of a Moving Magnet Phono preamp ensures optimal performance for vinyl enthusiasts.
Cutting-Edge Features, Unmatched Value
Standout features include a super-accurate Moving Magnet Phono preamp, digital and analog inputs for CDs, and a High Res DAC for advanced audio processing. HDMI ARC input allows seamless integration with your TV, controllable using your TV’s remote. The inclusion of a Sub Out jack provides flexibility to enhance your system with a subwoofer.
Premium Performance at an Affordable Price
The NAD D 3045 combines advanced capabilities typically found in more expensive components. Its High Res USB DACs and headphone amplifiers surpass competitors in cost-effectiveness. With 60wpc, low distortion, and high current capability, this power amplifier provides rare performance at its price point. Enjoy 45 years of audio excellence in one compact, energy-efficient, and iconic NAD package.
High-Resolution Audio Excellence
The NAD D 3045 delivers a lifelike and natural listening experience with High-Resolution Audio capabilities. Master Quality Authenticated (MQA) ensures accurate reproduction of Studio Master recordings, providing music enthusiasts with the full spectrum of sound. High Res downloads and streaming offer an artist’s studio experience, unmatched in fidelity.
Versatile Connectivity Options
The D 3045 is equipped with diverse inputs and circuits to accommodate your entire music collection. An Asynchronous USB input facilitates High Res streaming from computers using precision clock technology, minimizing jitter. Bluetooth wireless streaming with aptX HD caters to everyday convenience, while the inclusion of a Moving Magnet Phono preamp ensures optimal performance for vinyl enthusiasts.
Cutting-Edge Features, Unmatched Value
Standout features include a super-accurate Moving Magnet Phono preamp, digital and analog inputs for CDs, and a High Res DAC for advanced audio processing. HDMI ARC input allows seamless integration with your TV, controllable using your TV’s remote. The inclusion of a Sub Out jack provides flexibility to enhance your system with a subwoofer.
Premium Performance at an Affordable Price
The NAD D 3045 combines advanced capabilities typically found in more expensive components. Its High Res USB DACs and headphone amplifiers surpass competitors in cost-effectiveness. With 60wpc, low distortion, and high current capability, this power amplifier provides rare performance at its price point. Enjoy 45 years of audio excellence in one compact, energy-efficient, and iconic NAD package.
