AMPLIFIERS
NAD CI 8-120 DSP
8 Channel Amplifier
AMPLIFIERS
NAD CI 8-120 DSP
8 Channel Amplifier
- overview
- specifications
- features
- gallery
- downloads
The CI8-120 stands as a testament to NAD’s commitment to legendary high performance in audio amplification. This 8-channel amplifier is meticulously crafted to meet the demands of distributed audio systems, particularly those facing challenges such as demanding speaker loads and extended cable runs. Encased in a compact 1U chassis, this powerhouse of an amplifier not only steps up power output but also prioritizes ultimate rack economy without compromising on performance. As a 4-zone amplifier, the CI8-120 is a reliable workhorse that seamlessly combines audiophile-quality sound with substantial power, fundamentally reshaping how we perceive distributed audio systems. Its innovative design and engineering excellence set a new standard, ensuring that every aspect of your audio experience is elevated. With the CI8-120, NAD redefines the landscape of distributed audio systems, delivering unparalleled performance, reliability, and efficiency.
The CI8-120 stands as a testament to NAD’s commitment to legendary high performance in audio amplification. This 8-channel amplifier is meticulously crafted to meet the demands of distributed audio systems, particularly those facing challenges such as demanding speaker loads and extended cable runs. Encased in a compact 1U chassis, this powerhouse of an amplifier not only steps up power output but also prioritizes ultimate rack economy without compromising on performance. As a 4-zone amplifier, the CI8-120 is a reliable workhorse that seamlessly combines audiophile-quality sound with substantial power, fundamentally reshaping how we perceive distributed audio systems. Its innovative design and engineering excellence set a new standard, ensuring that every aspect of your audio experience is elevated. With the CI8-120, NAD redefines the landscape of distributed audio systems, delivering unparalleled performance, reliability, and efficiency.
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | |
|---|---|
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. LINE INPUT, SPEAKER OUT | |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Continuous Output Power into 8 Ohms | >120 W (all channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | >130 W (two channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Continuous output power into 4 ohms | >135 W (all channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | >230 W (two channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Continuous output power into 8 ohms at Bridged mode | >200 W (all channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | >320 W (two channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. THD (20 Hz – 20 kHz) | <0.05 % (1 W to 100 W, 8 ohms and 4 ohms) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Signal-to-Noise Ratio | >88 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Clipping power (all channels driven) | >130 W (1 kHz 8 ohms 0.1 % THD) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | >150 W (1 kHz 4 ohms 0.1 % THD) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Clipping power into 8 ohms at Bridged mode | >300 W (1 kHz 0.1 % THD – all channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | >400 W (1 kHz 0.1 % THD – two channels driven) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. IHF dynamic power (all channels driven) | 8 ohms: 125 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 4 ohms: 200 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 2 ohms: 180 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. IHF dynamic power (two channels driven) | 8 ohms: 145 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 4 ohms: 260 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 2 ohms: 300 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. IHF dynamic power (Bridged mode, all channels driven) | 8 ohms: 440 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 4 ohms: 350 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 2 ohms: 230 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. IHF dynamic power (Bridged mode, two channels driven) | 8 ohms: 480 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 4 ohms: 380 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | 2 ohms: 300 W |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Peak output current | >20 A (1 ohm, 1 ms) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Damping Factor | >110 (ref. 8 ohms, 20 Hz to 6.5 kHz) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Frequency Response | ±0.5 dB (20 Hz – 20 kHz) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Channel separation | >70 dB (1 kHz) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | >65 dB (10 kHz) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Maximum undistorted input level | 2900 mV |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Input sensitivity (for 120 W in 8 ohms, maximum volume) | 1150 mV |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Analog Input audio sense threshold (one channel with signal) | 3 ± 0.5 mVrms (ref. 100 Hz – 10 kHz) |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Trigger IN level | 3 – 30 Vdc |
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. Standby power | 0.5W |
| DIMENSION AND WEIGHT | |
|---|---|
| DIMENSION AND WEIGHT dimensions (W x H x D)* | 483 x 45 x 435 mm (19 1/16 x 1 13/16 x 17 3/16”) |
| DIMENSION AND WEIGHT Shipping Weight | 10 kg (22 lbs) |
Full Disclosure Power
Unleash the potential of your multi-room audio system with the CI 8-120 DSP’s Full Disclosure Power. Delivering a conservative 120 watts per channel at 8 ohms, bridgeable to 200 watts, and IHF Dynamic Power of 4 x 350 watts at 4 ohms, it effortlessly drives various speaker loads, ensuring unparalleled sonic performance.
Hybrid Digital Amplification
Elevate your audio experience with the CI 8-120 DSP’s Hybrid Digital Amplification. Customized Hypex UcD output stage provides load-invariant power, low distortion, and a minimal noise floor. Ideal for custom installations, it handles 4 ohm and 8 ohm loads seamlessly, making it versatile for long cable runs and demanding speaker setups.
Rack Space Efficiency and Reliability
Prioritize reliability and efficiency in your installations with NAD’s CI 8-120. Designed for stability, this amplifier ensures reliable performance. Its efficient use of rack space, with thermostatic fans for optimal cooling, addresses the practical needs of professional installers. Trust in a stable and compact solution for your audio setups.
Web UI/DSP Integration
Experience seamless setup and control with the CI 8-120’s Web UI/DSP integration. Network-ready for quick configuration via the custom WebUI, it allows easy adjustment of inputs, outputs, gain settings, and DSP profiles. Compatible with popular control systems, it offers flexibility with power-on options, Eco mode, and I/O switching. Elevate your audio control with advanced digital features.
Full Disclosure Power
Unleash the potential of your multi-room audio system with the CI 8-120 DSP’s Full Disclosure Power. Delivering a conservative 120 watts per channel at 8 ohms, bridgeable to 200 watts, and IHF Dynamic Power of 4 x 350 watts at 4 ohms, it effortlessly drives various speaker loads, ensuring unparalleled sonic performance.
Hybrid Digital Amplification
Elevate your audio experience with the CI 8-120 DSP’s Hybrid Digital Amplification. Customized Hypex UcD output stage provides load-invariant power, low distortion, and a minimal noise floor. Ideal for custom installations, it handles 4 ohm and 8 ohm loads seamlessly, making it versatile for long cable runs and demanding speaker setups.
Rack Space Efficiency and Reliability
Prioritize reliability and efficiency in your installations with NAD’s CI 8-120. Designed for stability, this amplifier ensures reliable performance. Its efficient use of rack space, with thermostatic fans for optimal cooling, addresses the practical needs of professional installers. Trust in a stable and compact solution for your audio setups.
Web UI/DSP Integration
Experience seamless setup and control with the CI 8-120’s Web UI/DSP integration. Network-ready for quick configuration via the custom WebUI, it allows easy adjustment of inputs, outputs, gain settings, and DSP profiles. Compatible with popular control systems, it offers flexibility with power-on options, Eco mode, and I/O switching. Elevate your audio control with advanced digital features.
MANUAL
DATA SHEET
CONTROL PROTOCOLS
CAD & PDF DRAWINGS
To download a copy of the firmware for your NAD unit please contact support
SOFTWARE
CHASSIS DRIVER
BROCHURE
MANUAL
DATA SHEET
CONTROL PROTOCOLS
CAD & PDF DRAWINGS
To download a copy of the firmware for your NAD unit please contact support
SOFTWARE
CHASSIS DRIVER
BROCHURE
The CI8-120 stands as a testament to NAD’s commitment to legendary high performance in audio amplification. This 8-channel amplifier is meticulously crafted to meet the demands of distributed audio systems, particularly those facing challenges such as demanding speaker loads and extended cable runs. Encased in a compact 1U chassis, this powerhouse of an amplifier not only steps up power output but also prioritizes ultimate rack economy without compromising on performance. As a 4-zone amplifier, the CI8-120 is a reliable workhorse that seamlessly combines audiophile-quality sound with substantial power, fundamentally reshaping how we perceive distributed audio systems. Its innovative design and engineering excellence set a new standard, ensuring that every aspect of your audio experience is elevated. With the CI8-120, NAD redefines the landscape of distributed audio systems, delivering unparalleled performance, reliability, and efficiency.
The CI8-120 stands as a testament to NAD’s commitment to legendary high performance in audio amplification. This 8-channel amplifier is meticulously crafted to meet the demands of distributed audio systems, particularly those facing challenges such as demanding speaker loads and extended cable runs. Encased in a compact 1U chassis, this powerhouse of an amplifier not only steps up power output but also prioritizes ultimate rack economy without compromising on performance. As a 4-zone amplifier, the CI8-120 is a reliable workhorse that seamlessly combines audiophile-quality sound with substantial power, fundamentally reshaping how we perceive distributed audio systems. Its innovative design and engineering excellence set a new standard, ensuring that every aspect of your audio experience is elevated. With the CI8-120, NAD redefines the landscape of distributed audio systems, delivering unparalleled performance, reliability, and efficiency.
| GENERAL SPECIFICATIONS All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive filter and AES 17 active filter. | |
|---|---|
| LINE INPUT, SPEAKER OUT | |
| Continuous Output Power into 8 Ohms | >120 W (all channels driven) |
| >130 W (two channels driven) | |
| Continuous output power into 4 ohms | >135 W (all channels driven) |
| >230 W (two channels driven) | |
| Continuous output power into 8 ohms at Bridged mode | >200 W (all channels driven) |
| >320 W (two channels driven) | |
| THD (20 Hz – 20 kHz) | <0.05 % (1 W to 100 W, 8 ohms and 4 ohms) |
| Signal-to-Noise Ratio | >88 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms) |
| Clipping power (all channels driven) | >130 W (1 kHz 8 ohms 0.1 % THD) |
| >150 W (1 kHz 4 ohms 0.1 % THD) | |
| Clipping power into 8 ohms at Bridged mode | >300 W (1 kHz 0.1 % THD – all channels driven) |
| >400 W (1 kHz 0.1 % THD – two channels driven) | |
| IHF dynamic power (all channels driven) | 8 ohms: 125 W |
| 4 ohms: 200 W | |
| 2 ohms: 180 W | |
| IHF dynamic power (two channels driven) | 8 ohms: 145 W |
| 4 ohms: 260 W | |
| 2 ohms: 300 W | |
| IHF dynamic power (Bridged mode, all channels driven) | 8 ohms: 440 W |
| 4 ohms: 350 W | |
| 2 ohms: 230 W | |
| IHF dynamic power (Bridged mode, two channels driven) | 8 ohms: 480 W |
| 4 ohms: 380 W | |
| 2 ohms: 300 W | |
| Peak output current | >20 A (1 ohm, 1 ms) |
| Damping Factor | >110 (ref. 8 ohms, 20 Hz to 6.5 kHz) |
| Frequency Response | ±0.5 dB (20 Hz – 20 kHz) |
| Channel separation | >70 dB (1 kHz) |
| >65 dB (10 kHz) | |
| Maximum undistorted input level | 2900 mV |
| Input sensitivity (for 120 W in 8 ohms, maximum volume) | 1150 mV |
| Analog Input audio sense threshold (one channel with signal) | 3 ± 0.5 mVrms (ref. 100 Hz – 10 kHz) |
| Trigger IN level | 3 – 30 Vdc |
| Standby power | 0.5W |
| DIMENSION AND WEIGHT | |
|---|---|
| Dimensions (W x H x D)* | 483 x 45 x 435 mm (19 1/16 x 1 13/16 x 17 3/16”) |
| Shipping Weight | 10 kg (22 lbs) |
Full Disclosure Power
Unleash the potential of your multi-room audio system with the CI 8-120 DSP’s Full Disclosure Power. Delivering a conservative 120 watts per channel at 8 ohms, bridgeable to 200 watts, and IHF Dynamic Power of 4 x 350 watts at 4 ohms, it effortlessly drives various speaker loads, ensuring unparalleled sonic performance.
Hybrid Digital Amplification
Elevate your audio experience with the CI 8-120 DSP’s Hybrid Digital Amplification. Customized Hypex UcD output stage provides load-invariant power, low distortion, and a minimal noise floor. Ideal for custom installations, it handles 4 ohm and 8 ohm loads seamlessly, making it versatile for long cable runs and demanding speaker setups.
Rack Space Efficiency and Reliability
Prioritize reliability and efficiency in your installations with NAD’s CI 8-120. Designed for stability, this amplifier ensures reliable performance. Its efficient use of rack space, with thermostatic fans for optimal cooling, addresses the practical needs of professional installers. Trust in a stable and compact solution for your audio setups.
Web UI/DSP Integration
Experience seamless setup and control with the CI 8-120’s Web UI/DSP integration. Network-ready for quick configuration via the custom WebUI, it allows easy adjustment of inputs, outputs, gain settings, and DSP profiles. Compatible with popular control systems, it offers flexibility with power-on options, Eco mode, and I/O switching. Elevate your audio control with advanced digital features.
Full Disclosure Power
Unleash the potential of your multi-room audio system with the CI 8-120 DSP’s Full Disclosure Power. Delivering a conservative 120 watts per channel at 8 ohms, bridgeable to 200 watts, and IHF Dynamic Power of 4 x 350 watts at 4 ohms, it effortlessly drives various speaker loads, ensuring unparalleled sonic performance.
Hybrid Digital Amplification
Elevate your audio experience with the CI 8-120 DSP’s Hybrid Digital Amplification. Customized Hypex UcD output stage provides load-invariant power, low distortion, and a minimal noise floor. Ideal for custom installations, it handles 4 ohm and 8 ohm loads seamlessly, making it versatile for long cable runs and demanding speaker setups.
Rack Space Efficiency and Reliability
Prioritize reliability and efficiency in your installations with NAD’s CI 8-120. Designed for stability, this amplifier ensures reliable performance. Its efficient use of rack space, with thermostatic fans for optimal cooling, addresses the practical needs of professional installers. Trust in a stable and compact solution for your audio setups.
Web UI/DSP Integration
Experience seamless setup and control with the CI 8-120’s Web UI/DSP integration. Network-ready for quick configuration via the custom WebUI, it allows easy adjustment of inputs, outputs, gain settings, and DSP profiles. Compatible with popular control systems, it offers flexibility with power-on options, Eco mode, and I/O switching. Elevate your audio control with advanced digital features.
