NAD has built a reputation for delivering cutting-edge, high-performance turntables that strike the perfect balance between innovation and affordability. Although the fundamental operation of a turntable may appear straightforward, the task of extracting every nuance of musical energy from record grooves while mitigating destructive resonances demands a harmonious blend of scientific precision and artistic finesse. Let’s delve into the components of the C 588, exploring the meticulous choices we’ve made to ensure a top-tier experience. From the high-quality turntable design to the intricacies of the motor turntable, each element reflects our commitment to delivering unparalleled audio quality.
NAD has built a reputation for delivering cutting-edge, high-performance turntables that strike the perfect balance between innovation and affordability. Although the fundamental operation of a turntable may appear straightforward, the task of extracting every nuance of musical energy from record grooves while mitigating destructive resonances demands a harmonious blend of scientific precision and artistic finesse. Let’s delve into the components of the C 588, exploring the meticulous choices we’ve made to ensure a top-tier experience. From the high-quality turntable design to the intricacies of the motor turntable, each element reflects our commitment to delivering unparalleled audio quality.
| GENERAL SPECIFICATIONS | |
|---|---|
|
GENERAL SPECIFICATIONS
Nominal speed
|
33/45 rpm, manual speed change
|
|
GENERAL SPECIFICATIONS
|
(78 rpm possible with special pulley
|
|
GENERAL SPECIFICATIONS
Speed variance
|
33 rpm: < ± 0.35 %, 45 rpm: < ± 0.30 %
|
|
GENERAL SPECIFICATIONS
Wow and flutter
|
<0.01% (ref. 1 kHz, Audio LPF)
|
|
GENERAL SPECIFICATIONS
Signal/Noise ratio
|
– 70 dB
|
|
GENERAL SPECIFICATIONS
Downforce range
|
0 – 30 mN
|
|
GENERAL SPECIFICATIONS
|
0 – 3.0 grams
|
|
GENERAL SPECIFICATIONS
Supplied counterweight system
|
95dB
|
|
GENERAL SPECIFICATIONS
Supplied counterweight system
|
Counterweight for cartridges: 6 – 13 g
|
|
GENERAL SPECIFICATIONS
Voltage
|
Universal switch mode power supply
|
|
GENERAL SPECIFICATIONS
|
15 V DC/0,8 A, 100-240 V AC, 47 – 63Hz
|
|
GENERAL SPECIFICATIONS
Power consumption
|
5 W max/ 0.3W standby
|
| TONEARM | |
|---|---|
|
TONEARM
Effective tonearm mass
|
9.5 g
|
|
TONEARM
Effective tonearm length
|
230 mm
|
|
TONEARM
Overhang
|
18 mm
|
| ORTOFON 2M RED CARTRIDGE | |
|---|---|
|
ORTOFON 2M RED CARTRIDGE
Frequency range
|
20-22.000Hz
|
|
ORTOFON 2M RED CARTRIDGE
Channel separation
|
22dB/1kHz
|
|
ORTOFON 2M RED CARTRIDGE
Output voltage
|
5.5 mV
|
|
ORTOFON 2M RED CARTRIDGE
Recommended load impedance
|
47 kohms/Amplifier connection: MM-input
|
|
ORTOFON 2M RED CARTRIDGE
Compliance/stylus type
|
20μm/mN – elliptical
|
|
ORTOFON 2M RED CARTRIDGE
Recommended tracking force
|
18 mN
|
|
ORTOFON 2M RED CARTRIDGE
Weight
|
7.2g
|
| DIMENSIONS AND WEIGHT | |
|---|---|
|
DIMENSIONS AND WEIGHT
Gross Dimensions (W x H X D)
|
17 1/8 x 13 7/16 x 4 15/16” (435 x 340 x 125mm)
|
|
DIMENSIONS AND WEIGHT
Shipping Weight
|
9.2 kg(20.3 lbs)
|
Precision Speed Control
The C 588 employs electronic speed control with a specialized synchronous clock motor, ensuring exact pitch and addressing Wow and Flutter issues. Isolating AC Mains, utilizing a unique belt, and precision machining eliminate vibrations, offering a high-quality turntable experience.
Exceptional Tonearm Design
Featuring a custom carbon fiber tonearm with a decoupled counterweight and magnetic anti-skate compensation, the C 588 prioritizes optimal tracking. The Ortofon 2M Red cartridge delivers nuanced sound, and the extended 9” tonearm allows for precise adjustments, including azimuth and vertical tracking angle.
Mechanical Triangle Integration
The turntable establishes a tight mechanical coupling between the platter and tonearm, forming a crucial triangle. Precision machining and assembly ensure minimal play in mechanical interfaces, preserving musical energy flow. NAD’s attention to detail enhances the turntable’s performance and longevity.
Resonance Control and Isolation Mastery
The C 588 minimizes spurious vibrations by strategically addressing internal and external sources. The massive MDF base, vibration damping feet, non-resonant dust cover, glass platter, felt pad, and carbon fiber tonearm collectively reduce vibrations, creating an optimal environment for the turntable’s motor and delivering a high-quality audio experience.
Precision Speed Control
The C 588 employs electronic speed control with a specialized synchronous clock motor, ensuring exact pitch and addressing Wow and Flutter issues. Isolating AC Mains, utilizing a unique belt, and precision machining eliminate vibrations, offering a high-quality turntable experience.
Exceptional Tonearm Design
Featuring a custom carbon fiber tonearm with a decoupled counterweight and magnetic anti-skate compensation, the C 588 prioritizes optimal tracking. The Ortofon 2M Red cartridge delivers nuanced sound, and the extended 9” tonearm allows for precise adjustments, including azimuth and vertical tracking angle.
Mechanical Triangle Integration
The turntable establishes a tight mechanical coupling between the platter and tonearm, forming a crucial triangle. Precision machining and assembly ensure minimal play in mechanical interfaces, preserving musical energy flow. NAD’s attention to detail enhances the turntable’s performance and longevity.
Resonance Control and Isolation Mastery
The C 588 minimizes spurious vibrations by strategically addressing internal and external sources. The massive MDF base, vibration damping feet, non-resonant dust cover, glass platter, felt pad, and carbon fiber tonearm collectively reduce vibrations, creating an optimal environment for the turntable’s motor and delivering a high-quality audio experience.
