Experience enhanced audio with the AMP1, a powerful hi-fi amplifier that seamlessly integrates into any stereo system. Boasting Chromecast built-in, this amplifier provides unparalleled flexibility, allowing you to effortlessly stream and cast music directly from your mobile device or preferred music streaming app. The AMP1 also features native Bluetooth® integration, enabling wireless connectivity to smartphones, tablets, and Bluetooth-enabled devices, delivering your favorite music with high-fidelity precision. NAD’s commitment to a music-first approach is evident in the AMP1’s design, incorporating advanced components typical of NAD’s leading amplifiers. The result is a low-noise circuitry that prioritizes detail and stability, producing near-zero distortion sound even for challenging speakers. Elevate your audio experience with the AMP1, where cutting-edge technology meets NAD’s renowned commitment to audio excellence.
Experience enhanced audio with the AMP1, a powerful hi-fi amplifier that seamlessly integrates into any stereo system. Boasting Chromecast built-in, this amplifier provides unparalleled flexibility, allowing you to effortlessly stream and cast music directly from your mobile device or preferred music streaming app. The AMP1 also features native Bluetooth® integration, enabling wireless connectivity to smartphones, tablets, and Bluetooth-enabled devices, delivering your favorite music with high-fidelity precision. NAD’s commitment to a music-first approach is evident in the AMP1’s design, incorporating advanced components typical of NAD’s leading amplifiers. The result is a low-noise circuitry that prioritizes detail and stability, producing near-zero distortion sound even for challenging speakers. Elevate your audio experience with the AMP1, where cutting-edge technology meets NAD’s renowned commitment to audio excellence.
| GENERAL SPECIFICATIONS | |
|---|---|
| GENERAL SPECIFICATIONS Rated Output Power into 4 Ohms and 8 Ohms (Stereo) | >40W (at rated THD, 20-20kHz, both channels driven)) |
| GENERAL SPECIFICATIONS IHF Dynamic Power | 4 Ohm 100W, 8 Ohm 50W |
| GENERAL SPECIFICATIONS THD (20Hz – 20kHz) | <0.03% (Rated power, 8 Ohms and 4 Ohms) |
| GENERAL SPECIFICATIONS Signal/Noise Ratio | >106dB (A-weighted, Optical input, ref. 40W out in 8 Ohms) |
| GENERAL SPECIFICATIONS Clipping power | >50W (at 1kHz 0.1% THD) |
| GENERAL SPECIFICATIONS Frequency response | ±0.3dB (20Hz-20kHz, 4-8 Ohms load) |
| GENERAL SPECIFICATIONS Input sensitivity (for 40W in 8 Ohms) | Line In: 450mV Digital In: -5dB FS |
| GENERAL SPECIFICATIONS Maximum input signal | >2.1Vrms (ref. 0.1% THD) |
| GENERAL SPECIFICATIONS Output impedance | 220 Ohms |
| GENERAL SPECIFICATIONS Maximum voltage output | >2.0V (ref. 0.1% THD) |
| GENERAL SPECIFICATIONS Support bit rate/sample rate | Up to 24bit/192kHz |
| GENERAL SPECIFICATIONS Standby Power | <0.5W (Off-mode), <3W (Network standby) |
| GENERAL SPECIFICATIONS Input sensitivity, Phono | 5mV (ref 40W 1kHz 8 Ohms out, volume maximum) |
| DIMENSION AND WEIGHT | |
|---|---|
| DIMENSION AND WEIGHT Dimensions (W x H x D) * | 220 x 63 x 252mm 8 5/8 x 2 1/2 x 10” ** |
| DIMENSION AND WEIGHT Net Weight | 4.85kg (10.7lb) |
Cutting-Edge Digital Amplification
Discover the revolutionary Clear and Pure Digital Amp Technology of the AMP1, featuring ESS Sabre 32Bit DACs in full balanced mode. With six separate power supplies, it ensures an optimal signal path, providing unparalleled performance and efficiency. Immerse yourself in a new era of audio excellence.
Efficient Class D Powerhouse
NAD’s relentless pursuit of audio perfection culminates in the AMP1’s Efficient Class D Power. Experience energy-efficient amplification that generates beautiful sound without compromising on heat. The highly linear design, coupled with advanced power supply technology, delivers consistent, noise-free performance, meeting the dynamic demands of your music.
Seamless Streaming Experience
Elevate your streaming possibilities with the AMP1’s Chromecast built-in and Bluetooth® integration. Effortlessly cast music, iTunes, podcasts, and playlists from your favorite devices. Enjoy limitless flexibility as you explore the vast world of music streaming, all seamlessly integrated into the AMP1 amplifier.
Versatile Connectivity
Unleash the full potential of the AMP1 with its Flexible Connectivity features. Connect a turntable to the built-in phono preamp for authentic vinyl listening. The wide array of connections accommodates analogue and digital sources, while low impedance line outputs enable subwoofer integration. Transform your TV experiences with crisp, high-fidelity sound, making the AMP1 the ultimate partner for your entertainment setup.
Cutting-Edge Digital Amplification
Discover the revolutionary Clear and Pure Digital Amp Technology of the AMP1, featuring ESS Sabre 32Bit DACs in full balanced mode. With six separate power supplies, it ensures an optimal signal path, providing unparalleled performance and efficiency. Immerse yourself in a new era of audio excellence.
Efficient Class D Powerhouse
NAD’s relentless pursuit of audio perfection culminates in the AMP1’s Efficient Class D Power. Experience energy-efficient amplification that generates beautiful sound without compromising on heat. The highly linear design, coupled with advanced power supply technology, delivers consistent, noise-free performance, meeting the dynamic demands of your music.
Seamless Streaming Experience
Elevate your streaming possibilities with the AMP1’s Chromecast built-in and Bluetooth® integration. Effortlessly cast music, iTunes, podcasts, and playlists from your favorite devices. Enjoy limitless flexibility as you explore the vast world of music streaming, all seamlessly integrated into the AMP1 amplifier.
Versatile Connectivity
Unleash the full potential of the AMP1 with its Flexible Connectivity features. Connect a turntable to the built-in phono preamp for authentic vinyl listening. The wide array of connections accommodates analogue and digital sources, while low impedance line outputs enable subwoofer integration. Transform your TV experiences with crisp, high-fidelity sound, making the AMP1 the ultimate partner for your entertainment setup.
MANUAL
FIRMWARE
To download a copy of the firmware for your NAD unit please contact support
DATA SHEET
MANUAL
FIRMWARE
To download a copy of the firmware for your NAD unit please contact support
DATA SHEET
Experience enhanced audio with the AMP1, a powerful hi-fi amplifier that seamlessly integrates into any stereo system. Boasting Chromecast built-in, this amplifier provides unparalleled flexibility, allowing you to effortlessly stream and cast music directly from your mobile device or preferred music streaming app. The AMP1 also features native Bluetooth® integration, enabling wireless connectivity to smartphones, tablets, and Bluetooth-enabled devices, delivering your favorite music with high-fidelity precision. NAD’s commitment to a music-first approach is evident in the AMP1’s design, incorporating advanced components typical of NAD’s leading amplifiers. The result is a low-noise circuitry that prioritizes detail and stability, producing near-zero distortion sound even for challenging speakers. Elevate your audio experience with the AMP1, where cutting-edge technology meets NAD’s renowned commitment to audio excellence.
Experience enhanced audio with the AMP1, a powerful hi-fi amplifier that seamlessly integrates into any stereo system. Boasting Chromecast built-in, this amplifier provides unparalleled flexibility, allowing you to effortlessly stream and cast music directly from your mobile device or preferred music streaming app. The AMP1 also features native Bluetooth® integration, enabling wireless connectivity to smartphones, tablets, and Bluetooth-enabled devices, delivering your favorite music with high-fidelity precision. NAD’s commitment to a music-first approach is evident in the AMP1’s design, incorporating advanced components typical of NAD’s leading amplifiers. The result is a low-noise circuitry that prioritizes detail and stability, producing near-zero distortion sound even for challenging speakers. Elevate your audio experience with the AMP1, where cutting-edge technology meets NAD’s renowned commitment to audio excellence.
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Output Power into 4 Ohms and 8 Ohms (Stereo) | >40W (at rated THD, 20-20kHz, both channels driven) |
| IHF Dynamic Power | 4 Ohm 100W, 8 Ohm 50W |
| THD (20Hz – 20kHz) | <0.03% (Rated power, 8 Ohms and 4 Ohms) |
| Signal/Noise Ratio | >106dB (A-weighted, Optical input, ref. 40W out in 8 Ohms) |
| Clipping power | >50W (at 1kHz 0.1% THD) |
| Frequency response | ±0.3dB (20Hz-20kHz, 4-8 Ohms load) |
| Input sensitivity (for 40W in 8 Ohms) | Line In: 450mV Digital In: -5dB FS |
| Maximum input signal | >2.1Vrms (ref. 0.1% THD) |
| Output impedance | 220 Ohms |
| Maximum voltage output | >2.0V (ref. 0.1% THD) |
| Support bit rate/sample rate | Up to 24bit/192kHz |
| Standby Power | <0.5W (Off-mode), <3W (Network standby) |
| Input sensitivity, Phono | 5mV (ref 40W 1kHz 8 Ohms out, volume maximum) |
| DIMENSIONS AND WEIGHT | |
|---|---|
| Dimensions (W x H x D) * | 220 x 63 x 252mm 8 5/8 x 2 1/2 x 10” ** |
| Net Weight | 4.85kg (10.7lb) |
Cutting-Edge Digital Amplification
Discover the revolutionary Clear and Pure Digital Amp Technology of the AMP1, featuring ESS Sabre 32Bit DACs in full balanced mode. With six separate power supplies, it ensures an optimal signal path, providing unparalleled performance and efficiency. Immerse yourself in a new era of audio excellence.
Efficient Class D Powerhouse
NAD’s relentless pursuit of audio perfection culminates in the AMP1’s Efficient Class D Power. Experience energy-efficient amplification that generates beautiful sound without compromising on heat. The highly linear design, coupled with advanced power supply technology, delivers consistent, noise-free performance, meeting the dynamic demands of your music.
Seamless Streaming Experience
Elevate your streaming possibilities with the AMP1’s Chromecast built-in and Bluetooth® integration. Effortlessly cast music, iTunes, podcasts, and playlists from your favorite devices. Enjoy limitless flexibility as you explore the vast world of music streaming, all seamlessly integrated into the AMP1 amplifier.
Versatile Connectivity
Unleash the full potential of the AMP1 with its Flexible Connectivity features. Connect a turntable to the built-in phono preamp for authentic vinyl listening. The wide array of connections accommodates analogue and digital sources, while low impedance line outputs enable subwoofer integration. Transform your TV experiences with crisp, high-fidelity sound, making the AMP1 the ultimate partner for your entertainment setup.
Cutting-Edge Digital Amplification
Discover the revolutionary Clear and Pure Digital Amp Technology of the AMP1, featuring ESS Sabre 32Bit DACs in full balanced mode. With six separate power supplies, it ensures an optimal signal path, providing unparalleled performance and efficiency. Immerse yourself in a new era of audio excellence.
Efficient Class D Powerhouse
NAD’s relentless pursuit of audio perfection culminates in the AMP1’s Efficient Class D Power. Experience energy-efficient amplification that generates beautiful sound without compromising on heat. The highly linear design, coupled with advanced power supply technology, delivers consistent, noise-free performance, meeting the dynamic demands of your music.
Seamless Streaming Experience
Elevate your streaming possibilities with the AMP1’s Chromecast built-in and Bluetooth® integration. Effortlessly cast music, iTunes, podcasts, and playlists from your favorite devices. Enjoy limitless flexibility as you explore the vast world of music streaming, all seamlessly integrated into the AMP1 amplifier.
Versatile Connectivity
Unleash the full potential of the AMP1 with its Flexible Connectivity features. Connect a turntable to the built-in phono preamp for authentic vinyl listening. The wide array of connections accommodates analogue and digital sources, while low impedance line outputs enable subwoofer integration. Transform your TV experiences with crisp, high-fidelity sound, making the AMP1 the ultimate partner for your entertainment setup.
MANUAL
FIRMWARE
To download a copy of the firmware for your NAD unit please contact support
DATA SHEET
